Saab 9000 1990-1993 Wheel housing, front

Group 8a Car body, external, section 260

Saab 9000 Wheel housing, front diagram
PosArticlePart No.
2Reinforcement9265844
3Reinforcement9265836
3Reinforcement4293726
4Wheel housing4100897 (replaces 9265554)
4Wheel housing4098711
4Wheel housing4100897 (replaces 4005542)
4Wheel housing4098729
5Towing hook6955678
6Bracket4293882
7Plate4098695 (replaces 6962609)
7Plate4098695
7Plate4098703 (replaces 6962617)
7Plate4098703
8Reinforcement9275793
8Reinforcement9275785
10Beam6961940
10Beam4009700
11Air shield9088675
12Plug8206096
13Plug9267915
14Plug9268178
15Plug9268863
16Seal9625641
17Seal8968133
17Bracket4117628
17Bracket4117610
17Bracket4117602
18Plug7038342
21Towing eye8668592
21Towing eye8670002
22Retaining plate8664021
22Retaining plate8670010
22Retaining plate9090119
23Locating plate8662207
23Clamping plate9090135
24Nut7974371
25Seal4009775
25Seal4009767
Weld screw7982952
Weld screw4348173
