Group 6 Front wheel suspension, section 350
| Pos | Article | Part No. |
|---|---|---|
| 1 | Belt tensioner | 4901443 (replaces 4029609) |
| 2 | Absorber | 4901419 (replaces 4028064) |
| 3 | Bushing kit | 4901476 (replaces 4029989) |
| 4 | Foundation platform | 4358149 (replaces 4028049) |
| 4 | Foundation platform | 4358149 |
| 5 | Tensioning arm | 4029799 |
| 6 | Washer | 92153033 (replaces 8029985) |
| 6 | Washer | 32000432 (replaces 9166372) |
| 7 | Screw | 8083941 |
| 8 | Snap ring | 8047748 |
| 9 | Bracket | 4027686 |
| 10 | Brace | 4027694 |
| 11 | Tension pulley | 4029930 |
| 12 | Screw | 4029864 |
| 13 | Screw | 92150014 (replaces 7978208) |
| 14 | Screw | 7978232 |
| 15 | Screw | 92150019 (replaces 7978257) |
| 20 | Tension pulley | 4901625 (replaces 7592017) |
| 21 | Bracket | 7593049 |
| 22 | Bushing | 7593072 |
| 22A | Bushing | 7593080 |
| 23 | Screw | 7978299 |
| 25 | Screw | 90511105 (replaces 8056194) |
