Group 5 Brakes, section 430
| Pos | Article | Part No. |
|---|---|---|
| 1 | Hose kit | 8967341 |
| Hose | 8966301 | |
| Nipple | 8966285 | |
| Needle | 8966293 | |
| O-ring | 8967408 | |
| 1 | Hose kit | 4002861 |
| Hose | 9104746 | |
| Nipple | 9104738 | |
| O-ring | 4003117 | |
| 2 | O-ring kit | 8967390 |
| O-ring | 8966681 | |
| Sleeve | 8966939 | |
| 3 | Pump kit | 8967424 |
| Pump motor | 8967440 | |
| O-ring | 8967234 | |
| O-ring | 8967325 | |
| 3 | Pump kit | 4003158 |
| Pump motor | 4003166 | |
| 4 | Master cylinder kit | 8967457 |
| Brake servo | 8967473 | |
| Master cylinder | 8966426 | |
| Valve body | 8966392 | |
| Connector | 8966376 | |
| Connector | 8966384 | |
| Rubber bushing | 4482568 (replaces 8966335) | |
| Nut | 8074106 | |
| Washer | 92153033 (replaces 7916497) | |
| 4 | Master cylinder kit | 4003182 |
| Master cylinder | 4003174 | |
| 5 | Screw kit | 32000324 (replaces 9105115) |
| Sleeve | 8967374 | |
| Screw | 8967382 | |
| 6 | Adjuster kit | 4107793 |
| Washer | 4107801 | |
| Adjustment screw | 4107793 (replaces 8955304) | |
| Screw | 8955312 | |
| Stop ring | 4107793 (replaces 8970147) |
