Saab 900 1986-1986 AC evaporator (Clarion)

Group 8c Heating and ventilation, section 370

Saab 900 AC evaporator (Clarion) diagram

Pos	Article	Part No.
1	Hose	8820201
2	O-ring	30541941 (replaces 7972094)
3	Condenser	8820177
4	Screw	8059578
5	Screw	7922420
6	Washer	8029951
7	Hose	8820219
8	O-ring	30541940 (replaces 7972086)
9	Hose	8820227
11	Clamp	9481458
11A	Spacer	9481441
12	Screw	8019911
13	Nut	8151227 (replaces 8029555)
14	Reservoir	8820185
14A	Switch	8821639
15	Clamp	9461088
16	Screw	55562873 (replaces 8082968)
17	Evaporator	8820169
18	Valve	8821431
19	O-ring	7972078
21	Screw	7922461
22	Nut	9465600
23	Hose	8820193
24	O-ring	4318044 (replaces 7972482)
25	Clamp	9480898
26	Screw	8019945
27	Lock nut	92150265 (replaces 8073512)
28	Shutter	8820151
47	Attaching plate	8821548
48	Screw	8821555
49	Protecting moulding	8278558
51	Clamp	7398373
52	Clamp	7398530
