Group 6 Front wheel suspension, section 240
| Pos | Article | Part No. |
|---|---|---|
| 1 | Pressure hose | 4247185 |
| 1 | Pressure hose | 4838819 (replaces 4399317) |
| 2 | O-ring | 4104048 |
| 3 | Clamp | 8566135 (replaces 7969371) |
| 4 | Plastic nut | 92152035 (replaces 4087128) |
| 5 | Suction hose | 4482725 |
| 5 | Suction hose | 4482782 |
| 5 | Suction hose | 4482733 |
| 7 | Screw | 11900353 (replaces 7978091) |
| 8 | Hose clamp | 7970072 |
| 9 | Hose | 4482741 |
| 9 | Hose | 4482998 |
| 9 | Hose | 4482758 |
| 9 | Hose | 4482774 |
| 10 | Hose clamp | 90572589 (replaces 7970056) |
| 11 | Hose clamp | 7970049 |
| 12 | Pressure hose | 5330451 (replaces 4482832) |
| 14 | Bracket | 4246567 |
| 15 | Bracket | 4242889 |
| 16 | Hexagon screw | 7978679 |
| 16 | Hexagon screw | 7978661 |
| 17 | Reservoir | 4482600 |
| 17 | Reservoir | 4646196 (replaces 4402103) |
| 17 | Reservoir | 4646196 |
| 18 | Cover | 4402798 |
| 18 | Cover | 30557111 (replaces 4402616) |
| 18A | Filter cartridge | 4193199 |
| 19 | Brace | 4242897 |
| 20 | Screw | 11900355 (replaces 7978117) |
| 21 | Clip | 4242962 |
| 22 | Clip | 4373668 |
| 23 | Pump, hydraulic oil | 4647491 (replaces 4400370) |
| 23 | Pump, hydraulic oil | 4647491 (replaces 4647376) |
| 23A | Pulley | 4960670 (replaces 4356085) |
| 23B | Pump, hydraulic oil | 4647491 |
| 23B | Pump, hydraulic oil | 4647392 (replaces 4400362) |
| 23B | Pump, hydraulic oil | 4647392 |
| 24 | Screw | 90470712 (replaces 8741449) |
| 25 | Pulley | 90409788 (replaces 4165171) |
| 26 | Screw | 55566034 (replaces 7978190) |
| 28 | Bracket | 4356077 |
| 29 | Bushing | 7593072 |
| 30 | Hexagon screw | 7982978 |
| 32 | Hexagon screw | 11900376 (replaces 7982523) |
| 33 | Hexagon screw | 11900367 (replaces 7978216) |
| 34 | Double clamp | 30550883 (replaces 4402095) |
| 35 | Tie strap | 30507607 (replaces 7593221) |
| 35 | Tie strap | 11900513 (replaces 7971880) |
| Sealing kit | 32000169 (replaces 4402780) |
