Group 6 Front wheel suspension, section 150
| Pos | Article | Part No. |
|---|---|---|
| 1 | Steering wheel | 4507448 |
| 1 | Steering wheel | 4507463 |
| 2 | Cable | 4629853 |
| 3 | Horn button | 4003372 |
| 3 | Horn button | 4003380 |
| 4 | Screw | 8968703 |
| 5 | Screw | 8968315 |
| 6 | Steering wheel | 4847794 (replaces 4506077) |
| 6 | Steering wheel | 4847794 |
| 6 | Steering wheel | 4506085 |
| 6 | Steering wheel | 4847802 |
| 7 | Cover | 4506317 |
| 7 | Cover | 4847810 |
| 8 | Bushing | 30557470 (replaces 4506150) |
| 8 | Seal | 4848289 |
| 9 | Signal device | 4506325 |
| 9 | Signal device | 4847828 |
| 10 | Screw | 4506416 |
| 11 | Screw | 30557473 (replaces 4506200) |
| 12 | Rubber damper | 5207360 (replaces 4506218) |
| 13 | Spring | 4506226 |
| 14 | Cable network | 4847869 (replaces 4506242) |
| 14 | Cable network | 4847869 |
| 16 | Steering wheel | 4532248 |
| 16 | Steering wheel | 400107546 (replaces 4532255) |
| 18 | Signal device | 5209341 (replaces 4506168) |
| 24 | Nut | 12779215 (replaces 8954315) |
| 25 | Washer | 8030058 |
| 26 | Contact unit | 4761417 (replaces 4416582) |
| 26 | Contact unit | 4848644 |
| 26 | Contact unit | 5331202 (replaces 5011705) |
| 27 | Screw | 7977283 |
| 28 | Cover | 12755283 (replaces 4506143) |
| 28 | Cover | 12755283 |
| 29 | Vibration damper | 4719050 |
| 30 | Vibration damper | 4761300 |
