Group 5 Brakes, section 320
| Pos | Article | Part No. |
|---|---|---|
| 1 | Brake pedal | 8991473 |
| 1 | Brake pedal | 9104472 |
| 1 | Brake pedal | 8991499 |
| 1 | Brake pedal | 9105768 |
| 2 | Bushing | 8407983 |
| 3 | Brake pedal | 8938136 |
| 3 | Brake pedal | 8941635 |
| 4 | Pedal pad | 8916272 |
| 4 | Pedal pad | 8956393 |
| 5 | Bracket | 8944407 |
| 5 | Bracket | 4103784 |
| 6 | Screw | 7979248 |
| 7 | Spacer tube | 8935132 |
| 8 | Bearing bushing | 8948051 |
| 9 | Lock nut | 92153199 (replaces 8151474) |
| 10 | Spring | 8941320 |
| 11 | Sealing washer | 8929531 |
| 12 | Nut | 92150143 (replaces 7971922) |
| 13 | Nut | 11900440 (replaces 8074288) |
| 14 | Bracket | 8944373 |
| 14 | Bracket | 9105925 |
| 14A | Bushing | 8912115 |
| 14B | Bushing | 8937625 |
| 15 | Bracket | 8938359 |
| 16 | Washer | 8030066 |
| 17 | Lock ring | 8047722 |
| 18 | Rod | 4003976 |
| 19 | Fork | 8924557 |
| 20 | Nut | 8151060 |
| 21 | Clip | 8933509 |
| 22 | Clip | 12780365 (replaces 8252553) |
| 23 | Bolt | 8956443 |
| 25 | Intermediate shaft | 8991382 |
| 25 | Intermediate shaft | 9105560 |
| 29 | Spring | 8935751 |
| 29 | Spring | 4191813 |
| 29 | Spring | 4199964 |
| 31 | Plug | 7163066 |
| 32 | Rubber plug | 8928699 |
| 34 | Plate | 8971582 (replaces 8942021) |
| 35 | Gasket | 8941478 |
| 36 | Washer | 8029993 |
