Saab 900 1994-1998 Outer universal joint

Group 4 Transmission, section 510

Saab 900 Outer universal joint diagram

Pos	Article	Part No.
1	Universal joint	30583376 (replaces 4399325)
3	Lock nut	8965360
4	Drive shaft	4247904
4	Drive shaft	4544854 (replaces 4242400)
4	Drive shaft	4544854
4	Drive shaft	4544862 (replaces 4248241)
4	Drive shaft	4544862
5	Universal joint	4242319
5	Universal joint	4242327
6	Companion flange	8950628
7	Companion flange	4544763 (replaces 4242376)
7	Companion flange	4544763
7	Companion flange	4544771 (replaces 4242384)
7	Companion flange	4544771
8	Lock ring	8921520
9	Lock ring	8950636
10	Bellows	4242459
10	Bellows kit	8994147
11	Clamp	4242467
11	Clamp	30519720 (replaces 8972986)
12	Clamp	4242475
13	Bellows	4483517 (replaces 4399333)
13	Bellows	4483517
14	Clamp	4483525 (replaces 4399341)
14	Clamp	4483525
15	Clamp	4195822
15	Clamp	4483533
20	Intermediate shaft	4237665
20	Intermediate shaft	4282265
20A	Grease	90513210 (replaces 8781684)
21	Bearing bracket	11900368 (replaces 4385985)
21	Bearing bracket	4926457
21	Bearing bracket	11900368 (replaces 4385993)
21	Bearing bracket	4926473
21A	Bushing	7593080
22	Bearing bracket	4237632
23	Ball bearing	4238432
24	Ring	8048324
25	Snap ring	4282257
26	O-ring	4282240
27	Lock ring	4282547
28	Bearing seat	4282273
29	Hexagon screw	11900367 (replaces 7978216)
31	Cotter pin	7974074
32	Screw	7978232
32	Screw	11900368 (replaces 7978224)
33	Hexagon screw	7978265
34	Spacer	4282281
35	Deadener weight	4645594 (replaces 4545091)
35A	Deadener weight	4645594
36	Screw	7978133
37	Grease	90007999 (replaces 8781676)
