Group 6 Front wheel suspension, section 220
| Pos | Article | Part No. |
|---|---|---|
| 1 | Pressure hose | 4909990 |
| 1 | Delivery pipe | 5058532 |
| 1 | Delivery pipe | 5390125 |
| 1 | Pipe | 5531785 |
| 1 | Delivery pipe | 5236104 |
| 1 | Hose | 12841758 |
| 1 | Cooling coil | 5058722 |
| 1 | Cooling coil | 5239231 |
| 1 | Delivery pipe | 5531769 |
| 1 | Delivery pipe | 5531793 (replaces 5236724) |
| 1 | Delivery pipe | 5531793 |
| 1 | Hose | 12766939 (replaces 12756695) |
| 1 | Hose | 12766939 |
| 2 | O-ring | 92152387 (replaces 5125042) |
| 2 | O-ring | 93188576 |
| 3A | Pressure hose | 5058730 |
| 3A | Pressure hose | 5239223 |
| 3A | Pressure hose | 5239249 |
| 3B | Banjo screw | 5125448 (replaces 8123911) |
| 3C | Sealing ring | 4905253 |
| 4 | Vibration insulator | 12783773 (replaces 5056056) |
| 4 | Vibration insulator | 12783773 (replaces 12790893) |
| 4 | Insulation | 12783773 |
| 5 | Delivery pipe | 32015402 (replaces 4839650) |
| 5 | Delivery pipe | 32015402 (replaces 5058219) |
| 5 | Delivery pipe kit | 32015402 |
| 5 | Delivery pipe | 5236039 (replaces 5062526) |
| 5 | Delivery pipe | 30507607 (replaces 4908489) |
| 5 | Delivery pipe | 5058201 |
| 5A | Sealing ring | 4839932 |
| 5B | Hollow screw | 4686226 |
| 5 | Delivery pipe | 5236039 |
| 5 | Delivery pipe | 32015402 (replaces 5531462) |
| 5 | Hose | 93169341 (replaces 12762309) |
| 5 | Delivery pipe kit | 93169341 |
| 5 | Hose | 12766945 |
| 5 | Delivery pipe kit | 32015403 |
| 5 | Delivery pipe | 5236047 |
| 5 | Delivery pipe | 12762311 (replaces 5531470) |
| 5 | Hose | 12762311 |
| 5 | Delivery pipe kit | 93169342 |
| 5 | Hose | 12766944 |
| 5 | Delivery pipe | 5236088 |
| 5 | Delivery pipe | 5531488 |
| 5 | Delivery pipe | 5236096 |
| 5 | Delivery pipe | 5531496 |
| 5 | Hose | 12756697 |
| 5 | Hose | 12766942 |
| 5 | Hose | 12756696 |
| 5 | Hose | 12766943 |
| 5A | Sealing ring | 12771933 |
| 5B | Hollow screw | 12771937 |
| 6 | O-ring | 93188575 |
| 7 | Clamp | 5059191 |
| 7 | Clamp | 5236054 |
| 7A | Clamp | 4909180 |
| 8 | Nut | 11900451 (replaces 7977929) |
| 8 | Nut | 11900451 (replaces 92150133) |
| 9 | Pump, hydraulic oil | 5230750 (replaces 4838447) |
| 9 | Pump, hydraulic oil | 5230750 |
| 9 | Pump, hydraulic oil | 4837803 |
| 9 | Pump, hydraulic oil | 5231220 |
| 9 | Pump, hydraulic oil | 5231212 |
| 9 | Pump, hydraulic oil | 5533328 |
| 9 | Pump, hydraulic oil | 13102542 (replaces 5236849) |
| 9 | Pump | 12756698 |
| 9A | Pump, hydraulic oil | 12801790 (replaces 5530167) |
| 9D | Hexagon screw | 11095911 (replaces 4771747) |
| 9B | Pulley | 4678488 |
| 9C | Screw | 11097651 (replaces 4348439) |
| 9E | Screw | 11094791 |
| 9F | Screw | 11094051 (replaces 9544594) |
| 9G | Washer | 93179080 |
| 10 | Screw | 55563211 (replaces 7978240) |
| 10 | Hexagon screw | 55563211 |
| 10 | Hexagon screw | 11900367 (replaces 7978216) |
| 11 | Screw | 32000289 (replaces 7982515) |
| 11 | Torx screw | 11900016 |
| 12 | Screw | 55566034 (replaces 7978190) |
| 12 | Screw | 11900365 |
| 12B | Screw | 92153215 (replaces 7979610) |
| 13 | Bracket | 4568358 |
| 15 | Reservoir | 4482600 |
| 16 | Cover | 4402798 |
| 17 | Brace | 4242897 |
| 18 | Screw | 11900355 (replaces 7978117) |
| 18 | Screw | 11900355 (replaces 92150003) |
| 19 | Hose clamp | 90572590 (replaces 5125455) |
| 20 | Suction hose | 12758037 (replaces 4835757) |
| 20 | Suction hose | 12758037 (replaces 5058177) |
| 20 | Suction hose | 12758037 (replaces 5174636) |
| 20 | Suction hose | 12758037 (replaces 5238282) |
| 20 | Suction hose | 12758037 |
| 20 | Suction hose | 5174628 (replaces 5058169) |
| 20 | Suction hose | 5174628 |
| 20 | Suction hose | 12758039 (replaces 5230792) |
| 20 | Suction hose | 12758039 |
| 20 | Suction hose | 12758038 (replaces 5236732) |
| 20 | Suction hose | 12758038 |
| 20 | Hose | 12756694 |
| 21 | Clip | 5333547 (replaces 4835765) |
| 21 | Clip | 5333547 |
| 21 | Clip | 4837860 |
| 22 | Screw | 92153209 (replaces 7982481) |
| 22 | Screw | 92153209 |
| 22 | Screw | 7971294 |
| 23 | Hose clamp | 90572589 (replaces 7970056) |
| 23 | Hose clamp | 90572590 |
| 24 | Clamp | 4028569 |
| 25 | Tie strap | 9525221 |
| 26 | Return pipe | 12766940 (replaces 4839635) |
| 26 | Return pipe | 12766940 (replaces 5059472) |
| 26 | Return pipe | 12766940 (replaces 5331046) |
| 26 | Return pipe | 12766940 (replaces 5238266) |
| 26 | Return pipe | 12766940 |
| 26 | Return pipe | 12766938 (replaces 4839643) |
| 26 | Return pipe | 12766938 (replaces 5059480) |
| 26 | Return pipe | 12766938 (replaces 5331053) |
| 26 | Return pipe | 12766938 (replaces 5238274) |
| 26 | Return pipe | 12766938 |
| 27 | Sealing ring | 12771934 |
| 28 | Banjo screw | 5125448 |
| 28 | Hollow screw | 12771936 |
| 29 | Tie strap | 11900513 (replaces 92150191) |
| 30 | Tie strap | 30507607 (replaces 7593221) |
| 32 | Screw | 92153146 (replaces 7972607) |
| 32 | Screw | 92153146 |
