Saab 9-5 (650) 2010-2011 Front and centre floor

Group 8a Car body, external, section 100

Saab 9-5 (650) Front and centre floor diagram
PosArticlePart No.
1Floor panel13354192 (replaces 13304631)
1Floor panel13354193 (replaces 13304630)
2Reinforcement13331030
2Reinforcement13331031
3Protecting plate13313425
4Sill12847578
4Sill12847579
5Insulator13239594
6Insulator13239596
7Clip nut13267489
8Washer13267487
9Retainer13267490
10Rivet11571109
11Nut24441317
12Screw94520301
13Insulation9019408
14Cover13280107
15Cover13239610
15Cover13239611
