Saab 9-5 (650) 2010-2011 Transmission

Group 2 Engine, section 610

Saab 9-5 (650) Transmission diagram

Pos	Article	Part No.
1	Cover	12623400
2	Sealing ring	12608750
5	O-ring	12593717
6	Hexagon screw	11588728
7	Sleeve	11588327
8	Pin	22531637
9	Tension pulley	12575509
10	Hexagon screw	11519173
11	Water pump	92149009
12	Hexagon screw	11588713
13	Gasket	12576326
14	Seal	12593045
15	Pulley	12611587
16	Hexagon screw	11588940
17	Pulley	12626355
18	Hexagon screw	11569873
19	Key	12601937
20	Timing chain	12616609
21	Timing chain	12616608
22	Hexagon screw	11518858
23	Chain tensioner	12609262
24	Gasket	12589477
25	Hexagon screw	11588255
26	Chain tensioner	12609258
27	Gasket	12589479
29	Chain tensioner	12609260
30	Gasket	12589478
32	Guide	12597417
34	Guide	12600462
36	Guide	12600461
38	Hexagon screw	11588725
39	Guide	12586961
40	Guide	12586960
41	Chain gear	12599721
42	Spring	12599725
43	Idler gear	12612838
44	Special screw	11588252
45	Idler gear	12600459
