Saab 9-5 (650) 2010-2011 Transmission

Group 2 Engine, section 600

Saab 9-5 (650) Transmission diagram

Pos	Article	Part No.
1	Timing chain	12600850
2	Chain	24461834
3	Chain guide	13104978
4	Screw	11588522
5	Guide rail	12588387
6	Screw	11518828
7	Chain guide	24449448
8	Screw	11516425
9	Chain tensioner	12608580
10	Oil jet	12577163
12	Chain	90537370
13	Chain tensioner	90537300
15	Chain gear	24424758
16	Woodruff key	24424855
17	Chain gear	55557168
18	Chain guide	90537369
20	Chain guide	90537299
22	Chain guide	90537336
24	Chain gear	90537298
25	Screw	11518061
26	Chain gear	12578515
27	Screw	11588844
28	Gear	12621505
29	Balance shaft	12587216
30	Bearing	12587220
31	Chain gear	55354439
32	Screw	11516327
33	Bearing	12581395
34	Screw	11588712
35	Balance shaft	12587215
36	Bearing	12587219
37	Chain gear	55354438
39	Screw plug	55561057
