Saab 9-3 (9440) 2003-2011 Brake operation

Group 5 Brakes, section 1300

Saab 9-3 (9440) Brake operation diagram

Pos	Article	Part No.
1	Pedal arrangement	12759616 (replaces 12793151)
1	Pedal arrangement	12759616
1	Pedal arrangement	12779115 (replaces 12793152)
1	Pedal arrangement	12779115
1	Pedal arrangement	12759618 (replaces 12793153)
1	Pedal arrangement	12759618
1	Pedal arrangement	12779116 (replaces 12793150)
1	Pedal arrangement	12779116
1	Pedal arrangement	12779114 (replaces 12793154)
1	Pedal arrangement	12779114
1	Pedal arrangement	12803486
1	Pedal arrangement	12779113
1	Pedal arrangement	12803487
1	Pedal arrangement	12779112
3	Insulation	9177089
3	Insulation	9177090
4	Clip	90214832
8	Nut	11094436
12	Pedel contact	55701395 (replaces 9185906)
12	Switch	55701395
12	Pedel contact	55701396 (replaces 9185907)
12	Pedel contact	55701396
13	Push rod	24403422
13	Push rod	24403423
16	Pedal pad	12800294
16	Pedal pad	12800299
17	Lock bolt	12800291
18	Washer	12800292
19	Clip	12800293
20	Insulation	9178952
21	Insulation	24434749
22	Nut	90191908
23	Pedal	12759615
24	Screw	92152021
25	Silicon grease	90167353
