Saab 9-3 (9440) 2005-2011 Transmission

Group 2 Engine, section 785

Saab 9-3 (9440) Transmission diagram

Pos	Article	Part No.
1	Tooth belt	93178812
2	Chain gear	93178380
3	Screw	93177298
4	Guide roller	93178807
5	Washer	93178972
6	Screw	93178810
7	Timing gear casing	93178975
7	Cover	93191371
8	Screw	93177417
9	Screw	93178833
9	Hexagon screw	93191372
10	Washer	93178977
11	Chain gear	93178823
12	Nut	93178824
13	Key	93179143
14	Bracket	55566199
14	Bracket	93191367
15	Screw	93178973
16	Spacer ring	93178974
17	Nut	93178813
18	Belt tensioner	55212159 (replaces 93178816)
18	Tension pulley	55212159 (replaces 93186866)
18	Belt tensioner	55212159
18	Idler pulley	55215666 (replaces 93191364)
18	Idler pulley	55215666
19	Screw	93178814
20	Screw	93178829
20	Screw	93191368
21	Crankshaft gear	93178821
22	Spacer ring	93178818
23	Screw	93178819
24	Timing gear casing	93178976
25	Screw	93178832
25	Screw	55203150
28	Engine timing parts, kit	93191278
