Saab 9-3 (9440) 2006-2011 Transmission

Group 2 Engine, section 735

Saab 9-3 (9440) Transmission diagram

Pos	Article	Part No.
1	Timing chain	12589011
1	Timing chain	12616608
2	Timing chain	12590920
2	Timing chain	12616609
3	Chain gear	12566656
3	Chain gear	12599724
4	Idler gear	12590923
4	Idler gear	12600459
4	Idler gear	12612839
5	Idler gear	12590922
5	Idler gear	12612838 (replaces 12600460)
5	Idler gear	12612838
6	Chain gear	12590921
6	Chain gear	12599721
7	Chain tensioner	12609258 (replaces 12596980)
7	Chain tensioner	12609258
8	Gasket	12589479
9	Hexagon screw	11588255
10	Spacer sleeve	11588846
11	Guide	12586961
11	Guide	12623514
12	Guide	12586963
12	Guide	12600462
15	Chain tensioner	12609262 (replaces 12596981)
15	Chain tensioner	12609262
16	Gasket	12589477
19	Guide	12597417
22	Guide	12589010
22	Guide	12600461
25	Chain tensioner	12609260 (replaces 12596979)
25	Chain tensioner	12609260
26	Gasket	12589478
29	Guide	12586960
29	Guide	12623513
30	Gear	12588273
30	Chain gear	12590682
30	Chain gear	12630917 (replaces 12603744)
30	Chain gear	12630917
30	Chain gear	12603745
30	Chain gear	12630916
31	Hexagon screw	11588279
32	Hexagon screw	11561619
33	Actuator solenoid	12636175
34	Special screw	11588252
35	O-ring	12593717
36	Spring	12590924
36	Spring	12599725
37	Sealing compound	93165267
