Saab 9-3 (9400) 1998-2003 Brake operation

Group 5 Brakes, section 250

Saab 9-3 (9400) Brake operation diagram

Pos	Article	Part No.
1	Cowl plate	4647996
1	Cowl plate	4647988
2	Plug	8575599
3	Seal	90156374 (replaces 4245635)
4	Seal	4345724
6	Spacer plate	4242087
7	Bracket	4398897
7	Bracket	4398939
7	Bracket	4398905
7	Bracket	5058805 (replaces 4398947)
7	Bracket	5058805
8	Brake pedal	90288481 (replaces 4244547)
8	Brake pedal	90288482 (replaces 4244570)
8	Brake pedal	90288483
8	Brake pedal	90538473 (replaces 4242020)
8	Brake pedal	90538473
9	Pedal pad	90105172 (replaces 4241832)
9	Pedal pad	4688594 (replaces 4244612)
10	Return spring	90304944
11	Clip	90278102 (replaces 4345443)
12	Pin	90222680 (replaces 4345435)
13	Piston rod	90468840
14	Screw	4241865
15	Washer	8073108
16	Nut	4345047
17	Lock spring	90373365 (replaces 4241881)
18	Bracket	4246591
18	Bracket	4247003
19	Screw	7985138
20	Pedal bracket	90193008 (replaces 4212148)
21	Washer	4345344
22	Nut	92150143 (replaces 7971922)
23	Nut	90191908 (replaces 4345419)
26	Rubber plug	4838025
